our products

images
GUARANTEED TECHNICAL PARTICULARS
PARTICULARS RAW MATERIALS & COATING
1. CLAMP & KIPPER ALUMINIUM LM6,DIE CASTING
2. U BOLT MILD STEEL,HOT DEEP GI
3. RIVET MILD STEEL,HOT DEEP GI
4. CROSS ARM MILD STEEL. HOT DEEP GI
5. HEX BOLT MILD STEEL. HOT DEEP GI
6. SPLIT PIN STAINLESS STEEL. ,PHOSPHORUS BRONZE
7. SPRING WASHER SPRING WASHER,ELECTRO PLATING
8. FLAT WASHER MILD STEEL. HOT DEEP GI
9. HEX NUT MILD STEEL. HOT DEEP GI
10. PACKING IN JUTE GUNNY BAG WITH PLASTIC BAG,MARK ON EACH BAG
11. LOAD 30 KN / AS REQUIRED
12. WEIGHT AS REQUIRED
13. SUITABLE CONDUCTOR DIA 7-12 MM
images
GUARANTEED TECHNICAL PARTICULARS
PARTICULARS RAW MATERIALS & COATING
1. CLAMP & KIPPER ALUMINIUM LM6,DIE CASTING
2. U BOLT MILD STEEL,HOT DEEP GI
3. RIVET MILD STEEL,HOT DEEP GI
4. CROSS ARM MILD STEEL. HOT DEEP GI
5. HEX BOLT MILD STEEL. HOT DEEP GI
6. SPLIT PIN STAINLESS STEEL. ,PHOSPHORUS BRONZE
7. SPRING WASHER SPRING WASHER,ELECTRO PLATING
8. FLAT WASHER MILD STEEL. HOT DEEP GI
9. HEX NUT MILD STEEL. HOT DEEP GI
10. PACKING IN JUTE GUNNY BAG WITH PLASTIC BAG,MARK ON EACH BAG
11. LOAD 30 KN / AS REQUIRED
12. WEIGHT AS REQUIRED
13. SUITABLE CONDUCTOR DIA 7-12 MM
images
GUARANTEED TECHNICAL PARTICULARS
PARTICULARS RAW MATERIALS & COATING
1. CLAMP & KIPPER ALUMINIUM LM6,DIE CASTING
2. U BOLT MILD STEEL,HOT DEEP GI
3. RIVET MILD STEEL,HOT DEEP GI
4. SOCKET FORGED. HOT DEEP GI
5. SECURITY CLIP STAINLESS STEEL. , PHOSPHORUS BRONZE
6. BALL LINK FORGED. HOT DEEP GI
7. CROSS ARM MILD STEEL. HOT DEEP GI
8. HEX BOLT MILD STEEL. HOT DEEP GI
9. SPLIT PIN STAINLESS STEEL. , PHOSPHORUS BRONZE
10. SPRING WASHER SPRING WASHER,ELECTRO PLATING
11. FLAT WASHER MILD STEEL. HOT DEEP GI
12. HEX NUT MILD STEEL. HOT DEEP GI
13. PACKING IN JUTE GUNNY BAG WITH PLASTIC BAG,MARK ON EACH BAG
14. LOAD 45 KN / AS REQUIRED
15. WEIGHT AS REQUIRED
16. SUITABLE CONDUCTOR DIA 11-18 MM
images
GUARANTEED TECHNICAL PARTICULARS
PARTICULARS RAW MATERIALS & COATING
1. CLAMP & KIPPER ALUMINIUM LM6,DIE CASTING
2. U BOLT MILD STEEL,HOT DEEP GI
3. RIVET MILD STEEL,HOT DEEP GI
4. SOCKET FORGED. HOT DEEP GI
5. SECURITY CLIP STAINLESS STEEL. , PHOSPHORUS BRONZE
6. BALL LINK FORGED. HOT DEEP GI
7. CROSS ARM MILD STEEL. HOT DEEP GI
8. HEX BOLT MILD STEEL. HOT DEEP GI
9. SPLIT PIN STAINLESS STEEL. , PHOSPHORUS BRONZE
10. SPRING WASHER SPRING WASHER,ELECTRO PLATING
11. FLAT WASHER MILD STEEL. HOT DEEP GI
12. HEX NUT MILD STEEL. HOT DEEP GI
13. PACKING IN JUTE GUNNY BAG WITH PLASTIC BAG,MARK ON EACH BAG
14. LOAD 45 KN / AS REQUIRED
15. WEIGHT AS REQUIRED
16. SUITABLE CONDUCTOR DIA 11-18 MM
images
GUARANTEED TECHNICAL PARTICULARS
PARTICULARS RAW MATERIALS & COATING
1. CLAMP & KIPPER ALUMINIUM LM6,DIE CASTING
2. U BOLT MILD STEEL,HOT DEEP GI
3. RIVET MILD STEEL,HOT DEEP GI
4. CROSS ARM MILD STEEL. HOT DEEP GI
5. HEX BOLT MILD STEEL. HOT DEEP GI
6. SPLIT PIN STAINLESS STEEL. , PHOSPHORUS BRONZE
7. SPRING WASHER SPRING WASHER,ELECTRO PLATING
8. FLAT WASHER MILD STEEL. HOT DEEP GI
9. HEX NUT MILD STEEL. HOT DEEP GI
10. PACKING IN JUTE GUNNY BAG WITH PLASTIC BAG,MARK ON EACH BAG
11. LOAD 45 KN / AS REQUIRED
12. WEIGHT AS REQUIRED
13. SUITABLE CONDUCTOR DIA 11-16 MM
images
GUARANTEED TECHNICAL PARTICULARS
PARTICULARS RAW MATERIALS & COATING
1. CLAMP & KIPPER ALUMINIUM LM6,DIE CASTING
2. U BOLT MILD STEEL,HOT DEEP GI
3. RIVET MILD STEEL,HOT DEEP GI
4. SOCKET FORGED. HOT DEEP GI
5. SECURITY CLIP STAINLESS STEEL. , PHOSPHORUS BRONZE
6. BALL LINK FORGED. HOT DEEP GI
7. CROSS ARM MILD STEEL. HOT DEEP GI
8. HEX BOLT MILD STEEL. HOT DEEP GI
9. SPLIT PIN STAINLESS STEEL. , PHOSPHORUS BRONZE
10. SPRING WASHER SPRING WASHER,ELECTRO PLATING
11. FLAT WASHER MILD STEEL. HOT DEEP GI
12. HEX NUT MILD STEEL. HOT DEEP GI
13. PACKING IN JUTE GUNNY BAG WITH PLASTIC BAG,MARK ON EACH BAG
14. LOAD 45 KN / 70 KN / AS REQUIRED
15. WEIGHT AS REQUIRED
16. SUITABLE CONDUCTOR DIA 12-22 MM
images
GUARANTEED TECHNICAL PARTICULARS
PARTICULARS RAW MATERIALS & COATING
1. CLAMP & KIPPER ALUMINIUM LM6,DIE CASTING
2. U BOLT MILD STEEL,HOT DEEP GI
3. RIVET MILD STEEL,HOT DEEP GI
4. CROSS ARM MILD STEEL. HOT DEEP GI
5. HEX BOLT MILD STEEL. HOT DEEP GI
6. SPLIT PIN STAINLESS STEEL. , PHOSPHORUS BRONZE
7. SPRING WASHER SPRING WASHER,ELECTRO PLATING
8. FLAT WASHER MILD STEEL. HOT DEEP GI
9. HEX NUT MILD STEEL. HOT DEEP GI
10. PACKING IN JUTE GUNNY BAG WITH PLASTIC BAG,MARK ON EACH BAG
11. LOAD 45 KN / AS REQUIRED
12. WEIGHT AS REQUIRED
13. SUITABLE CONDUCTOR DIA 11-21 MM
images
GUARANTEED TECHNICAL PARTICULARS
PARTICULARS RAW MATERIALS & COATING
1. CLAMP & KIPPER ALUMINIUM LM6,DIE CASTING
2. U BOLT MILD STEEL,HOT DEEP GI
3. RIVET MILD STEEL,HOT DEEP GI
4. SOCKET FORGED. HOT DEEP GI
5. SECURITY CLIP STAINLESS STEEL. ,PHOSPHORUS BRONZE
6. BALL LINK FORGED. HOT DEEP GI
7. CROSS ARM MILD STEEL. HOT DEEP GI
8. HEX BOLT MILD STEEL. HOT DEEP GI
9. SPLIT PIN STAINLESS STEEL. ,PHOSPHORUS BRONZE
10. SPRING WASHER SPRING WASHER,ELECTRO PLATING
11. FLAT WASHER MILD STEEL. HOT DEEP GI
12. HEX NUT MILD STEEL. HOT DEEP GI
13. MILD STEEL. HOT DEEP GI IN JUTE GUNNY BAG WITH PLASTIC BAG,MARK ON EACH BAG
14. LOAD 70 KN / 90 KN / AS REQUIRED
15. WEIGHT AS REQUIRED
16. SUITABLE CONDUCTOR DIA 18-26 MM
images
GUARANTEED TECHNICAL PARTICULARS
PARTICULARS RAW MATERIALS & COATING
1. CLAMP & KIPPER ALUMINIUM LM6,DIE CASTING
2. U BOLT MILD STEEL,HOT DEEP GI
3. RIVET MILD STEEL,HOT DEEP GI
4. CROSS ARM MILD STEEL. HOT DEEP GI
5. HEX BOLT MILD STEEL. HOT DEEP GI
6. SPLIT PIN STAINLESS STEEL. ,PHOSPHORUS BRONZE
7. SPRING WASHER SPRING WASHER,ELECTRO PLATING
8. FLAT WASHER MILD STEEL. HOT DEEP GI
9. HEX NUT MILD STEEL. HOT DEEP GI
10. PACKING IN JUTE GUNNY BAG WITH PLASTIC BAG,MARK ON EACH BAG
11. LOAD 70 KN / AS REQUIRED
12. WEIGHT AS REQUIRED
13. SUITABLE CONDUCTOR DIA 18-28 MM
images
GUARANTEED TECHNICAL PARTICULARS
PARTICULARS RAW MATERIALS & COATING
1. CLAMP & KIPPER ALUMINIUM LM6,DIE CASTING
2. U BOLT MILD STEEL,HOT DEEP GI
3. RIVET MILD STEEL,HOT DEEP GI
4. SOCKET EYE FORGED. HOT DEEP GI
5. SECURITY CLIP STAINLESS STEEL. ,PHOSPHORUS BRONZE
6. BALL HOOK FORGED. HOT DEEP GI
7. SPLIT PIN STAINLESS STEEL. ,PHOSPHORUS BRONZE
7. SPRING WASHER SPRING WASHER, ELECTRO PLATING
8. FLAT WASHER MILD STEEL. HOT DEEP GI
9. HEX NUT MILD STEEL. HOT DEEP GI
10. PACKING IN JUTE GUNNY BAG WITH PLASTIC BAG,MARK ON EACH BAG
11. LOAD 45 - 90 KN / AS REQUIRED
12. WEIGHT AS REQUIRED
13. SUITABLE CONDUCTOR DIA 13-28 MM
images
GUARANTEED TECHNICAL PARTICULARS
PARTICULARS RAW MATERIALS & COATING
1. CLAMP & KIPPER ALUMINIUM LM6,DIE CASTING
2. U BOLT MILD STEEL,HOT DEEP GI
3. RIVET MILD STEEL,HOT DEEP GI
4. SOCKET FORGED. HOT DEEP GI
5. SECURITY CLIP STAINLESS STEEL. ,PHOSPHORUS BRONZE
6. BALL LINK FORGED. HOT DEEP GI
7. CROSS ARM MILD STEEL. HOT DEEP GI
8. HEX BOLT MILD STEEL. HOT DEEP GI
9. SPLIT PIN STAINLESS STEEL. ,PHOSPHORUS BRONZE
10. SPRING WASHER SPRING WASHER,ELECTRO PLATING
11. FLAT WASHER MILD STEEL. HOT DEEP GI
12. HEX NUT MILD STEEL. HOT DEEP GI
13. PACKING IN JUTE GUNNY BAG WITH PLASTIC BAG,MARK ON EACH BAG
14. LOAD 70 KN / 90 KN / AS REQUIRED
15. WEIGHT AS REQUIRED
16. SUITABLE CONDUCTOR DIA 12-26 MM
images
GUARANTEED TECHNICAL PARTICULARS
PARTICULARS RAW MATERIALS & COATING
1. CLAMP & KIPPER ALUMINIUM LM6,DIE CASTING
2. U BOLT MILD STEEL,HOT DEEP GI
3. RIVET MILD STEEL,HOT DEEP GI
4. SOCKET FORGED. HOT DEEP GI
5. SECURITY CLIP STAINLESS STEEL. ,PHOSPHORUS BRONZE
6. BALL LINK FORGED. HOT DEEP GI
7. CROSS ARM MILD STEEL. HOT DEEP GI
8. HEX BOLT MILD STEEL. HOT DEEP GI
9. SPLIT PIN STAINLESS STEEL. ,PHOSPHORUS BRONZE
10. SPRING WASHER SPRING WASHER,ELECTRO PLATING
11. FLAT WASHER MILD STEEL. HOT DEEP GI
12. HEX NUT MILD STEEL. HOT DEEP GI
13. PACKING IN JUTE GUNNY BAG WITH PLASTIC BAG,MARK ON EACH BAG
14. LOAD 70 KN / 90 KN / AS REQUIRED
15. WEIGHT AS REQUIRED
16. SUITABLE CONDUCTOR DIA 12-26 MM
images
GUARANTEED TECHNICAL PARTICULARS
PARTICULARS RAW MATERIALS & COATING
1. CLAMP & KIPPER ALUMINIUM LM6,DIE CASTING
2. U BOLT MILD STEEL,HOT DEEP GI
3. BOLT/RIVET MILD STEEL,HOT DEEP GI
4. SOCKET EYE FORGED. HOT DEEP GI
5. SECURITY CLIP W / R TYPE,STAINLESS STEEL., PHOSPHORUS BRONZE
6. BALL LINK FORGED. HOT DEEP GI
7. SHACKLE FORGED. HOT DEEP GI
8. SPLIT PIN STAINLESS STEEL. ,PHOSPHORUS BRONZE
9. SPRING WASHER SPRING WASHER,ELECTRO PLATING
10. FLAT WASHER MILD STEEL. HOT DEEP GI
11. HEX NUT MILD STEEL. HOT DEEP GI
12. PACKING IN JUTE GUNNY BAG WITH PLASTIC BAG,MARK ON EACH BAG
13. LOAD 90 KN / 120 KN / AS REQUIRED
14. WEIGHT AS REQUIRED
15. SUITABLE CONDUCTOR DIA 28-45 MM
images
GUARANTEED TECHNICAL PARTICULARS
PARTICULARS RAW MATERIALS & COATING
1. CLAMP & KIPPER ALUMINIUM LM6,DIE CASTING
2. U BOLT MILD STEEL,HOT DEEP GI
3. BOLT/RIVET MILD STEEL,HOT DEEP GI
4. SOCKET EYE FORGED. HOT DEEP GI
5. SECURITY CLIP W / R TYPE,STAINLESS STEEL., PHOSPHORUS BRONZE
6. BALL LINK FORGED. HOT DEEP GI
7. SHACKLE FORGED. HOT DEEP GI
8. YOKE PLATE MILD STEEL, HOT DEEP GI
9. TURNBUCKLE FORGED. HOT DEEP GI
10. SPLIT PIN STAINLESS STEEL. ,PHOSPHORUS BRONZE
11. SPRING WASHER SPRING WASHER,ELECTRO PLATING
12. FLAT WASHER MILD STEEL. HOT DEEP GI
13. HEX NUT MILD STEEL. HOT DEEP GI
14. PACKING IN JUTE GUNNY BAG WITH PLASTIC BAG/WOODEN CRATES,MARK ON EACH BAG
15. LOAD 90 KN / 120 KN / AS REQUIRED
16. WEIGHT AS REQUIRED
17. SUITABLE CONDUCTOR DIA AS REQUIRED
